IP66K Test Devices

Name: IP66K Test Devices
Brand: Xi'an LIB Environmental Simulation Industry

IP66K test devices incorporates IP6X test devices and IPX6K test devices, respectively for products’ shell tightness’ dustproof testing under 2kg ~ 4kg/m³dust concentration, and waterproof tests under impact of 2.5M ~ 3M distance high-pressure water jets.

Standard and customized IP66K test devices are available,get a quote today.

Model: DI-800, DI-1000, DI-1500, DI-2000, R6K-1200

Standard: IEC 60529, IP5X, IP6X, IPX5, IPX6, IPX6K, ISO20653, IEC 60068-2-68, IEC 60598, MIL-STD-810G

Features and Benefits of IP66K Test Devices

1. Dust test equipment and waterproof test equipment have circulation systems (dust cycle, water cycle), saving test resources.

2. Programmable test program, fully automatic test, improve test efficiency and prevent damage caused by misoperation.

3. High strength integrated structure and SUS304 material, the equipment can withstand long-term sand and water jet corrosion.

4. The IP66K test devices can be used for a variety of product testing, including electronic equipment, auto parts, lamps, etc., a wide range of applications.

Specifications of IP6X Test Device

Model	DI800	DI1000	DI1500	DI2000
Internal Dimension (mm)	80010001000	100010001000	100015001000	100020001000
Overall Dimension (mm)	104014501960	133014501960	133019501990	133024501990
Useful Volume (L)	800	1000	1500	2000
Temperature Range	Ambient ~ +50℃
Humidity Range	< 30% RH
Normal Wire Diameter	50um
Nominal Width of a Gap Between wires	75um
Fight Time	0 ~ 99H59M
Blowing Time	0 ~ 99H59M
Specimen Power Outlet	Dustproof socket 16A
Controller	Programmable color LCD touch mesh sieve controller, Ethernet connection
Safety Device	Overtemperature Protection; Overcurrent Protection; Earth Leakage Protection; Phase Sequence Protection
Exterior Material	A3 Steel Plate with protective coating
Interior Material	SUS304 stainless steel
Standard Configuration	Sample shelf, dust wiper, talcum powder(5kgs)
Power	AC380V 50Hz

Configuration of IP6X Test Device

① Workroom	Dust comes out from the top, dust comes back from the bottom, and the sample can be hung on the sample holder for more comprehensive exposure to dust Light, observation window, dust brush for monitoring the test process.
② Dust circulation system	It is composed of circulating fan, dust storage and vibration motor. The centrifugal fan drives the air flow into O-shape. The dust that naturally falls from the working room is stored in the dust storage.
③ Heating system	The heating pipe heats the dust filtered by the wire diameter is 50μm, the screen size is 75μm, to prevent the sand and dust from caking. It also provides heat for the workroom.
④ Control system	PLC program control LCD screen, can operate and set test procedures and parameters.

-----------------------------------------------

Specifications of IPX6K Test Device

Model			R6K-1200
Internal Dimensions (mm)			100012001000 DWH
Overall Dimensions (mm)			115035502100 DWH
Interior Volume (L)			1200
Parameter	Testing Platform Diameters		600mm
	Testing Platform Speed		5±1 r.p.m
	Turntable loads		50kgs
	Testing Platform Height		200-400 mm (adjustable)
	IPX6K	Internal Diameter of Nozzle	6.3mm
		Water Flow Rate	75 L/min +/- 5%
		Water pressure	1000 Kpa
		Distance from Water Spraying to Specimens	between 2.5 m and 3 m.

Configuration of IPX6K Test Device

① Workroom	Water with a range of 2.5M to 3M hits the sample on the turntable from the left side with adjustable height and speed of 1 to 7r/min. The SUS304 workroom is resistant to high pressure water shock and corrosion.
② Nozzle	Equipped with IPX5 and IPX6 nozzles, two water resistance levels can be tested. The nozzle is equipped with a flow meter, the flow rate is accurately controlled at 75L/min±5%, and the nozzle pressure is 1000kPa.
③ Control system	PLC programmable controller with touch screen, can set the test parameters, such as spray time, water flow, water pressure, sample table speed, etc., while real-time monitoring of the test process parameters.
④ Water system	Including water tank, water pump, filter, sensor. The tank stores the filtered water, the pump provides pressure to the nozzle, and the sensor monitors the flow.
