UVA Aging Machine

Name: UVA Aging Machine
Brand: Xi'an LIB Environmental Simulation Industry

The UVA aging machine installs UV lamps to simulate UVA ultraviolet radiation in natural sunlight, with a wavelength of 315-400nm, high intensity and stable UV radiation. Spray system and refrigeration system to create condensation, high temperature, high humidity and other environmental conditions, and perform accelerated weather resistance test on materials.

The temperature range can be from ambient to 90℃, humidity ≥95%RH, blackboard temperature（BPT） is 35℃ ~ 80℃, in order to simulate different climatic conditions, accelerate product aging.

Model: UV-SI-260,UV-260

Standard: ASTM G154, ASTM D 4329 – 05, ASTM C1257, ASTM C1442, ASTM C1519, ASTM C793, ASTM D1148, ASTM D3424, ASTM D3451, ASTM D4101, ASTM D4811, ASTM D6577, ASTM D6662

UVA Aging Machine Test Chamber Features and Benefits

1. The UVA aging machine can focus on the simulation of the long wave ultraviolet (UVA) band (315-400nm), which accounts for a relatively large proportion of sunlight's ultraviolet rays and has strong penetration.

2. Through the combination of enhanced UVA irradiation intensity and extreme environmental conditions (high temperature, rain), the aging process of the material in the natural environment for months or even years can be simulated in a relatively short time.

3. Equipped with water circulation system, automatic water intake and automatic filtration to ensure the smooth work of the spray system, save water resources.

4. Flexible and versatile sample holder customization to meet standard flat plate and complex 3D samples.

Specifications of UVA Aging Machine

Model	UV-SI-260
Internal Dimension (mm)	4501170500
Overall Dimension (mm)	61013301470
Specimen Holder Size(mm)	75*150
Specimen Capacity	56 Pieces
Irradiation Source	Fluorescent UV lamps (8) - 40 W
Temperature Range	Ambient ～ 90 ℃ ±2℃
Black Panel Temperature (BPT)	35 ～ 80 ℃
Humidity Range	≥95% RH
Bandwidth	290 ~ 400nm
Irradiance Control	0.3~20 W/㎡
Water Spray Cycle	1~9999H59M (Adjustable)
Distance of Specimen and lamp	50mm
Controller	Programmable color LCD touch screen controller, Ethernet connection
Water Supply System	Automatic water supply, Water purification system
Safety Device	Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection
Exterior Material	Steel Plate with protective coating
Interior Material	SUS304 stainless steel

Configuration of UVA Aging Machine

① Control system	The programmable controller and LCD touch screen can easily set the parameters of ultraviolet radiation intensity, irradiation time, temperature, humidity and so on through the control panel, and can also monitor and record the data during the test in real time.
② Test sample area	Flat specimen holders, aluminum panels with rings. Each specimen size is 75mm*150mm,can hold 52 pieces. In addition to the standard flat holder, you can select the3-D specimen holder for option.
③ Radiometer	Measure the radiant energy power density of ultraviolet rays. Irradiance Control UV-260: N/A UV-SI-260: 0.15 ~ 5 W/m² (340nm / 313nm)
④ Black panel	BPT= The temperature transmitted by hot air (working room) + The temperature produced by irradiation by a light source Generally it represents the highest possible temperature for the sample.
⑤ Water spray system	10 nozzles are installed,each side is 5 nozzles The settlement is 0.8-1.0ml /80cm² /H The flow is about 0.3L /m Automatic water supply.
⑥ Lighting system	8 lamps, 3 options, 4 UVA tubes, 4 UVB tubes, 8 UVA/UVB tubes, 40W each. Spectral power distribution (SPD) does not change with lamp aging, even when used for up to 5000 hours.
⑦ Heating system	Nickel-chromium alloy heater, located at the bottom of the workroom, heating efficiency is fast, high temperature up to 90℃.
