Thermal Shock Environmental Chamber

Name: Thermal Shock Environmental Chamber
Brand: Xi'an LIB Environmental Simulation Industry

LIB thermal shock environmental chamber contains a high temperature chamber(+220℃) and a low temperature chamber(-75℃). The samples are placed in a movable hanging basket to realize the impact of temperature change. It is used to test material structure or composite materials, which can be tolerated by extreme high temperature and extremely low temperature in an instant, so as to detect chemical changes or physical damage caused by thermal expansion or contraction of the sample in the shortest time.

Model: TS-162, TS-340, TS-500, TS-1000

Standard: AAMA501, ASTM D4169-16, IEC 61215, IEC 61646, IEC61108, IEC62688, MIL-STD-813D

Thermal Shock Environmental Chamber Features and Benefits

1. The thermal shock environmental chamber has high temperature chamber and low temperature chamber independently, which can be vertically distributed up and down or horizontally left and right.

2. The conversion speed of samples between high and low temperature chambers is fast, generally only 3 seconds, which can quickly simulate the environment with rapid temperature changes.

3. Fast cooling/heating speed, high temperature room and low temperature room can be restored to ambient within 30 minutes.

4. Applicable to electronics, automotive, aerospace, military, medical and other industries, can be used for various materials, parts, equipment temperature impact test.

Specifications of Thermal Shock Environmental Chamber

Model		TS-162	TS-340	TS-500	TS-1000
Internal Dimensions (mm)		300300250	450450360	650650500	850850700
Overall Dimension (mm)		15608701545	171010201845	191012202265	211014202665
Interior Volume (mm)		22L	72L	211L	505L
Loading Capacity		20kg	30kg	50kg	60kg
Pre-heat Room	Upper limit Temperature	+220℃
	Heating Time	Ambient ~ + 200℃, within 30 minutes
Pre-cool Room	Lower limit Temperature	-75℃
	Cooling time	Ambient ~ -70℃, within 30 minutes
Test Room	High Temperature Exposure Range	Ambient +20 ~ +200°C
	Low temperature Exposure Range	–65 ~ -5°C
Temperature Fluctuation		≤±0.5℃
Temperature Deviation		≤±3 ℃
Temperature Recovery Time		Within 5 minutes
Cooling System		Mechanical compression refrigeration system
Controller		Programmable color LCD touch screen controller, Ethernet connection
Safety Device		Over-temperature protection, Over-current protection; Refrigerant high-pressure protection; Earth leakage protection
Exterior Material		Steel Plate with protective coating
Interior Material		SUS304 stainless steel
Observation Window		Interior lighting, double-layer thermo stability silicone rubber sealing
Standard Configuration		2 shelves

Configuration of Thermal Shock Environmental Chamber


① Workroom SUS304 stainless steel hanging basket, fast movement (3 seconds) between high and low temperature chamber through mechanical transmission system.	② Hot room Located on the upper side. The heating element can raise the temperature in the high temperature chamber to about 220°C.

③ Cold room Located on the lower side, the refrigeration system works through the compressor and cooling cycle, which can reduce the temperature to -70°C.	④ Air circulation system The air circulation system is provided with a circulating air duct at the back of the high/low temperature room to ensure uniform temperature in the high/low temperature room.

⑤ Control system The PID control function regulates heating and cooling systems based on real-time temperature data. The temperature shock test procedure can be set.	⑥ Air supply The air compressor provides power to realize the functions of the pneumatic switch of the basket.
