IPX8 Test Equipment

IPX8 test equipment is used to check and confirm whether the product complies with the IEC 60529 IPX8 waterproof grade.The IPX8 rating means that the product can work at a certain depth of water for a long time without damage.

The water pressure is adjusted from 1 meter depth to 50 meters depth test the water resistance of the product and observe whether the item under test has water seepage.


Model: R78-600

Standard: GJB 150.8-86, ISO 20653, IEC 60529, UL 50E, UL 1598, UL 153,  UL1573, UL 60950-1, IPX7, IPX8

Features and Benefits of IPX8 Test Equipment

1. Good pressure bearing, cylindrical container design, symmetrical structure, uniform stress distribution, in the high pressure waterproof test can maintain structural stability and sealing.



2. The tank shell and internal components are made of 304 stainless steel, with good corrosion resistance and wear resistance, stable performance and long service life.



3. Accurate pressure control, equipped with a complete internal intake control system and pressure sensor, can simulate the water pressure environment of 1-50m under different water depths.



4. Monitoring system can be installed in the cylinder tank to monitor the sample during test and to observe the situation, such as bubbling, so as to find the leakage point of the product shell in time.



Specifications of IPX8 Test Equipment

Model

R78-600

Internal Dimension (mm)

Diameter 600mm * Height 1500 mm

Overall Dimension (mm)

Diameter 800mm * Height 1800 mm

Pressure

50m water depth pressure

Open mode

Pneumatic lid

Material

A3 steel plate, wall thickness 15mm

Controller

Programmable color LCD touch screen controller, Ethernet connection

Water Supply System

Storage water tank, Automatic water supply



Configuration of IPX8 Test Equipment






①Pressure relief valve

When the internal pressure of the equipment exceeds the set safe value, it automatically opens for pressure relief.

②Safety lock

  • 12 manual safety locks, the operator manually rotate the lock, tighten the bolts and other ways to lock the equipment.

  • And pneumatic bar can realize the function of opening/closing the cover.

③Controller cabinet

Set pressure value, test time, temperature, etc.; Control equipment pressure, pressure retention, pressure relief operations; Real-time monitoring of equipment operating status.

④Feet supporter

3 M8 hole Z-shaped tripod with good grip,fixed with the floor, increase stability.

⑤Air supply

Providing compressed air, which is the power source for the equipment to perform pressure tests.






⑥Temperature sensor

The temperature sensor with 0.001 degree precision is used to measure the temperature inside the IPX8 test equipment.

⑦Pressure sensor

Real-time monitoring of pressure changes inside IPX8 test equipment.



⑧Sample holder

For placing test samples, 50kg load bearing, height adjustable.

⑨Haft

Sample holder can aligned on both sides of the haft.
