Temperature Cycle Chamber

Name: Temperature Cycle Chamber
Brand: Xi'an LIB Environmental Simulation Industry

The temperature cycle chamber tests the performance of products under drastic temperature variations, ranging from -20℃, -40℃, and -70℃ to +180℃. It achieves this by means of rapid heating and cooling rates, typically 5℃ to 15℃ per minute, and cyclically alternating between high and low temperatures.

This process accelerates the manifestation of defects such as material thermal expansion and solder joint fractures. It is also effective in detecting thermal fatigue, cracking, or functional failures of materials caused by sudden temperature changes.

Model: TR5-100, TR5-225, TR5-500, TR5-800, TR5-1000

Standard: AAMA501, ASTM D4169-16, IEC 61215, IEC 61646, IEC61108, IEC62688, MIL-STD-811D

Thermal Cycle Chamber Features and Benefits

1. Wide temperature range, from extremely low temperatures (-70°C) to high temperatures (+150°C). The temperature control accuracy is ±0.5℃.

2. Meet MIL-STD-810, IEC 60068, JESD22 and other international test standards.

3. The fast heating and cooling speed can be controlled according to different test requirements, and the rate can reach 5℃/10℃/15℃/20℃/min.

4. Temperature and humidity cycle test, thermal shock test, long-term temperature aging test and other tests to meet the diverse needs of different products and materials

Specifications of Thermal Cycle Chamber

Model	TR5-100	TR5-225	TR5-500	TR5-800	TR5-1000
Internal Dimension (mm)	400500500	500600750	700800900	80010001000	100010001000
Overall Dimension (mm)	90010501620	100011401870	120013402020	130015402120	150015402140
Interior Volume	100L	225L	500L	800L	1000L
Heat load	1000W
Temperature Range	A : -20℃ ~ +150 ℃ B : -40℃ ~ +150 ℃ C: -70℃ ~ +150 ℃
Temperature Fluctuation	± 0.5 ℃
Temperature Deviation	± 2.0 ℃
Cooling Rate	10℃/min (15℃/min)
Heating Rate	10℃/min (15℃/min)
Controller	Programmable color LCD touch screen controller, Multi-language interface, Ethernet , USB
Cooling System	Mechanical compression refrigeration system
Exterior Material	Steel Plate with protective coating
Interior Material	SUS304 stainless steel
Power Supply	380V
Maximum Noise	65 dBA

Details of Thermal Cycle Chamber


Workroom Provide a closed temperature control space to simulate extreme temperature environments. 304 stainless steel (corrosion resistance, high and low temperature impact resistance). 10CM high density polyurethane foam insulation.	Refrigeration system Two-stage cascade refrigeration achieves rapid cooling and low temperature maintenance, ensuring extreme temperature changes. Cooling rate 5℃/ min, linear controllable.

Cable hole External cable or power supply for real-time sample performance monitoring. Standard configuration: 1 Φ50mm test hole.	Air circulation system Centrifugal high temperature fan (quiet, long life), to ensure uniform working room temperature field, accelerate heat exchange efficiency. Top air supply + bottom air return to form vertical laminar flow, temperature uniformity ≤±0.5℃.

The LIB temperature cycle chamber accurately simulates extreme temperature conditions, and according to your specific requirements, our professional technical team and after-sales support guarantee your experience. If you are interested, leave your requirements and the LIB team will contact you within 24 hours.
