Benchtop Temperature Humidity Chamber

Name: Benchtop Temperature Humidity Chamber
Brand: Xi'an LIB Environmental Simulation Industry

LIB benchtop temperature humidity chamber includes a standard temperature and humidity system with small size, and explosion-proof series models, which are mainly used for temperature and humidity testing of batteries. Small products can be tested with this small benchtop test chamber, which has a small capacity, small footprint, and stable performance.

Three low temperature is -20℃，-40℃，-70℃ and the highest temperature can reach at +150℃.Humidity ranges from 20%RH to 98%RH.

Model: TH-80A, TH-80B, TH-80C

Standard: AAMA501, ASTM D4169-16, IEC 61215, IEC 61646, IEC61108, IEC62688, MIL-STD-812D

Benchtop Temperature Humidity Chamber Features and Benefits

1. The benchtop laboratory humidity chamber for simulating temperature and humidity systems are available in a wide range of low temperature ranges.

2. 50L and 80L models are very popular. LIB Industry benchtop thermal chamber is small in size and equipped with casters for easy movement.

3. The internal material of the chamber is mirror surface SUS304 stainless steel, which has the characteristics of beauty and corrosion resistance.

4. The benchtop programmable temperature humidity chamber can be connected to mobile devices for remote control, and can also be connected to a computer for operation.

Benchtop Temperature Humidity Chamber Specifications

Model	TH-50	TH-80
Internal Dimension (mm)	320350450	400400500
Overall Dimension (mm)	8201160950	90012101000
Interior Volume	50L	80L
Heat load	1000W
Temperature Range	A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃
Temperature Fluctuation	± 0.5 ℃
Temperature Deviation	± 2.0 ℃
Humidity Range	20% ~ 98% RH
Humidity Deviation	± 2.5% RH
Cooling Rate	1 ℃ / min
Heating Rate	3 ℃ / min
Cooling system	Mechanical compression refrigeration system
Controller	Programmable color LCD touch screen controller Ethernet connection
Safety Device	Humidifier Dry-combustion protection; Over-temperature Protection; Over-current Protection; Refrigerant High-pressure protection; Water Shortage Protection; Earth leakage Protection
Exterior Material	Steel Plate with protective coating
Interior Material	SUS304 stainless steel
Thermal Insulation	Polyurethane foam and insulation cotton
Observation Window	Interior lighting, double-layer thermo stability silicone rubber sealing
Standard Configuration	1 Cable hole (Φ 50,) with plug; 2 shelves
Weight	190kgs		220kgs

Configuration of Benchtop Thermal Chamber

benchtop thermal chamber bulk supplier

① Workroom	The benchtop thermal chamber shell is made of 4mm A3 steel plate, and the surface is treated by electrostatic spraying. The workroom uses mirror SUS304 stainless steel, which is resistant to corrosion, high temperature and easy to clean. PT-100 Class A temperature sensor, accuracy at 0.001 degrees. A wet gauze and a real-time temperature, converted by temperature difference, showing real-time relative humidity. Equipped with observation Windows and lighting. Standard double-layer punching sample rack, easy to air circulation, standard bearing 50KG, adjustable height.
② Control system	Programmable color LCD touch screen controller, user-friendly interface, can set temperature, humidity, test time and other parameters, and real-time monitoring.
③ Air circulation system	The air circulation system is composed of fan, return air outlet, supply air outlet and air duct. The fan drives the air to flow in the benchtop temperature and humidity chamber, so that the temperature and humidity distribution is more uniform.
④ Heating system	Nickel-chromium alloy electric heating heater, etc., can quickly and evenly heat the air inside the benchtop thermal chamber.
⑤ Water system	The evaporative humidifier can convert water into water vapor and increase the humidity inside the test chamber.
⑥ Cooling system	The use of mechanical compression refrigeration system, the original French "Taikang" fully enclosed compressor, etc., can quickly and effectively reduce the temperature inside the test chamber.
